Name: NEC MultiSync V552-TM 55-inch Infrared Touch Display (Discontinued)
Brand: NEC
SKU: nec-v552-tm
Availability: Discontinued

Overview

The NEC MultiSync V552-TM is a 55-inch infrared touch display that NEC has discontinued. It supports up to six simultaneous touch points, works without host PC drivers or calibration, and offers a 1920 x 1080 panel with 450 cd/m² brightness. It suits meeting rooms and training areas in Qatar that already run this model or need a like-for-like replacement. Request a quote for a current equivalent.

What the NEC V552-TM is and where it stands now

The NEC MultiSync V552-TM is a 55-inch large format display with an infrared touch overlay, part of the MultiSync V Series. NEC has discontinued this model, so this page is written for organisations that already own one, buyers comparing it with newer models, and anyone searching for a replacement. SmartRooms Qatar can quote for a current equivalent or a compatible replacement that matches your room, your PCs and your software.

Touch performance that needs no driver

The touch system uses infrared sensing and supports up to six simultaneous touch points, with native multi-touch on Windows 7 and Windows 8. Finger, gloved hand and stylus input are all listed as usable methods. The panel connects to the host computer over USB HID, so no driver, calibration routine or application software has to be installed on the PC. The touch system is described as calibration-free, with an accuracy below 2 mm. Linux, Mac OS X and Android are listed for single-touch use.

Picture, panel and mounting facts that matter

Panel: AMVA3 with edge LED backlight, native 1920 x 1080 at 60 Hz, 16:9.
Brightness and contrast: 450 cd/m² and a typical contrast ratio of 4000:1, with 178-degree viewing angles.
Front glass: 4 mm fully tempered, double-sided anti-reflection, 96% light transmission.
Size and weight: 1294.4 x 765.2 x 86.5 mm without stand, 40.8 kg.
Mounting: 300 x 300 mm VESA pattern with M6 holes.

Connections, expansion and remote management

Inputs include DisplayPort, DVI-D with HDCP, HDMI 1.3, a 15-pin D-sub, composite and component video on BNC, and a 3.5 mm audio input. Control is available over 100 Mbit LAN, RS232 and a remote control wire input. The STv2 OPS slot, compatible with the Intel and NEC OPS standard, accepts listed optional modules for HD-SDI, HDBaseT reception and a slot-in PC. Remote management includes LAN with SNMP, the free NaViSet Administrator 2 software, a scheduler and automatic alarm emails.

Where it fits in Qatar

A 55-inch panel suits a classroom in an international school in Doha, a meeting room in a West Bay office where staff work in Arabic and English side by side, or a training room in Education City. The wide viewing angles keep text readable for a group seated around a table. The listed operating range is 0 to +40°C, so plan for air-conditioned rooms rather than lobbies with glass frontage or outdoor-facing positions, where summer heat and dust can exceed what the product is rated for.

What to plan before ordering

Check the room climate: the operating range is 0 to +40°C with humidity of 20 to 80%.
Confirm the wall structure before mounting, because 40.8 kg needs a secure bracket.
Map the cable route and the power outlet, and decide whether an OPS module is needed.
Consider the optional 15 W + 15 W speakers for larger rooms.

SmartRooms Qatar offers a free site survey before wall-mounting, along with supply, professional installation and delivery to all eight municipalities of Qatar. Organisations buying several units can order through a purchase order (LPO) or a government tender. The manufacturer lists a 3-year warranty that includes the backlight.

Because this model is discontinued, request a quote today for a current equivalent or a compatible replacement. Quotations are usually issued within one working day.

Highlights

Up to six simultaneous infrared touch points
Driver-free USB HID connection to the host PC
Calibration-free touch system, accuracy below 2 mm
Native 1920 x 1080 panel at 450 cd/m²
4 mm tempered, anti-reflection front glass
OPS slot, LAN with SNMP and RS232 control

Classroom fit

At 55″ the farthest student should sit within about 4.1 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

64 specifications · Source: manufacturer · checked Oct 2026

Product Information3

Product Name: NEC MultiSync® V552-TM (Infrared Touch)
Product Group: LCD 55" Value Large Format Touch Display
Order Code: 60003678

Display9

Panel Technology: AMVA3 with Edge LED backlights
Active Screen Area (W x H) [mm]: 1,209.6 x 680.4
Screen Size [inch/cm]: 55 / 140
Aspect Ratio: 16:9
Brightness [cd/m²]: 450, 172 Eco (shipment setting)
Contrast Ratio (typ.): 4000:1
Viewing Angle [°]: 178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Response Time (typ.) [ms]: 6.5 (grey-to-grey)
Panel Refresh Rate [Hz]: 60

Touch7

Touch Technology: Infrared
Number of Touches: Real multi-touch up to 6 touches
Response Time [ms]: 0 to 20
Touch Method: Finger; Gloves; Stylus
Supported Operating System: Native Multi-Touch: Windows7, Windows8; Single Touch (Windows XP, Windows Vista, Linux, MAC OS X, Android)
Accuracy [mm]: < 2
Touch Resolution: 32767 x 32767

Protective Glass4

Type: Double sided anti-reflection, fully tempered
Thickness [mm]: 4
Light Transmission [%]: 96 (+/- 2 %)
Reflection Rate [%]: 2

Resolution3

Native Resolution: 1920 x 1080 at 60 Hz
Supported Resolutions: 1024 x 768; 1140 x 900; 1280 x 1024; 1280 x 720; 1280 x 768; 1280 x 800; 1280 x 960; 1366 x 786; 1400 x 1050; 1600 x 1200; 1680 x 1050; 1920 x 1080; 640 x 480; 720 x 400; 720 x 480; 720 x 576; 800 x 600
Supported on digital inputs (Video): 1280 x 720p (50)16:9; 1920 x 1080i (59.94/60)16:9; 1920 x 1080p (23.97/24)16:9; 1920 x 1080p (25)16:9; 1920 x 1080p (29.97/30)16:9; 1920 x 1080p (50)16:9; 1920 x 1080p (59.94/60)16:9; 720 x 480p (59.94/60)16:9; 720 x 576p (50)16:9

Synchronisation Rate2

Horizontal Frequency [kHz]: 31.5 - 91.1 (analog and digital)
Vertical Frequency [Hz]: 25.2 - 85

Connectivity9

Input Video Analogue: 1 x D-sub 15 pin; Composite (BNC); RGBHV for PC and Component/Composite (BNC)
Input Video Digital: 1 x DisplayPort; 1 x DVI-D (with HDCP); 1 x HDMI 1.3
Input Audio Analogue: 1 x 3,5 mm jack
Input Audio Digital: 1 x HDMI; DisplayPort
Input Control: LAN 100Mbit; remote control wire (3,5mm jack); RS232
Output Video Digital: 1 x DVI-D
Output Audio Analogue: 3,5mm jack
Output Control: RS232
Remote Control: LAN with SNMP; Remote Control IR (internal/external (optional) sensor); RS-232C (9-pin D-sub) Input and Output

Option Slot4

Slot Technology: STv2 (compatible with Intel / NEC OPS standard)
Inrush Current [A]: max. 10
Power Consumption [W]: max. 61
Voltage / Current [V/A]: 16/4

Electrical3

Power Consumption [W]: 96 Eco (shipment setting)
Power Savings Mode [W]: < 0.5 (ECO Standby); < 1
Power Management: VESA DPMS

Environmental Conditions4

Operating Temperature [°C]: +0 to +40
Operating Humidity [%]: 20 to 80
Storage Humidity [%]: 10 to 90
Storage Temperature [°C]: -20 to +60

Mechanical5

Dimensions (W x H x D) [mm]: Without stand: 1,294.4 x 765.2 x 86.5
Weight [kg]: Without stand: 40.8
Bezel Width [mm]: 41.4 (left/right); 41.4 (top/bottom)
VESA Mounting [mm]: 300 x 300 (FDMI); 4 holes; M6
Ingress Protection: IP40 (front); IP20 (back)

Available Options2

Accessories: Feet (ST-4620); Speaker (SP-RM1); Trolley (PDMHA, PDMHM-L); Wall mount (PDWHM-M, PDW S 32-55 L and P, PDW T L L and P)
OPS Slot: HD-SDI 1.5, 3.5; HDBaseT receiver; Slot-inPC (Intel® Core i5/i7 with WS7P recommended)

Regulatory1

Safety and Ergonomics: C-tick; CE; FCC Class B; PSB; RoHS; TÜV GS; UL/C-UL or CSA; VCCI

Green Features2

Energy Efficiency: Ambient Light Sensor; Annual energy consumption: 139 kWh (based on 4 operating hours per day); Carbon Savings Meter; ECOMode; Energy Efficiency Class: A
Ecological Materials: Manuals on CD; Optional feet

Additional Features6

Special Characteristics: Advanced fan control; Automatic Alarm E-Mails; Copy display settings through RS232; DICOM Simulation; Hardware colour calibration possible; Input name adjustment; Matrix memory; NaViSet Administrator 2 - free download; OSD rotation for portrait mode; Scheduler; Screen saver functions; TileMatrix (10 x 10); User input priority definition; Various picture in picture options
Audio: Integrated Speakers (10 W + 10 W); Optional Speakers (15 W + 15 W)
Plug and Play: VESA DDC2Bi
Shipping Content: Display; DVI-D cable; Free LAN control software (download); Power Cable; Remote Control; USB cable
Warranty: 3 years warranty incl. backlight
Operating Hours: 16/7

Downloads

4 files from the manufacturer

PDF Datasheets V552-TM_Datasheet.pdf 282 KB PDF Manuals & guides External_Control_Rev.4.4.pdf 367 KB PDF Brochures Warranty-and-Services_Interactive_Computing.pdf 1.0 MB PDF Brochures · Opens on manufacturer site SharpProduct_Overview.pdf

Questions about V552-TM

Is the NEC V552-TM still in production?

No. NEC has discontinued the MultiSync V552-TM, a 55-inch infrared touch display with a 1920 x 1080 panel and up to six touch points. SmartRooms Qatar can supply a current equivalent or a compatible replacement for schools, offices and meeting rooms across Qatar. Request a quote with your room size, required inputs and touch needs, and we will recommend the closest available option in the quotation.

What should I buy instead of the V552-TM?

Tell the SmartRooms Qatar team which features you rely on from the V552-TM, such as the 55-inch size, infrared touch, the driver-free USB HID connection or the OPS slot. We will quote a current equivalent or compatible replacement that keeps those functions, and confirm compatibility with your PC, software and wall mount before you issue a purchase order.

How many touch points does it support?

The display supports up to six simultaneous touch points using infrared touch technology. Native multi-touch is listed for Windows 7 and Windows 8. On other systems, including Windows XP, Windows Vista, Linux, Mac OS X and Android, the data lists single-touch support only. Finger, gloved hand and stylus input are all listed as usable methods, which suits teachers who write with a stylus.

Do I need to install drivers on my PC?

No driver is required on the host PC. The V552-TM connects over USB HID, and the manufacturer states that no drivers, calibration routines or application software are needed on the host. The touch system is described as calibration-free, so re-calibration is not part of normal use. This simplifies rollouts across several classroom PCs or meeting room computers managed by an IT team.

Will it work with a Mac or Linux laptop?

It connects to Mac and Linux computers over USB HID, but multi-touch is listed as native only on Windows 7 and Windows 8. Mac OS X and Linux are listed for single-touch support. If teachers in your school use a mix of Windows and Mac laptops, confirm the operating system of each device before ordering, and ask SmartRooms Qatar to check the video connection on the laptop you plan to use.

Is it suitable for medical imaging?

The data lists DICOM support for medical applications and a DICOM simulation feature. Whether the display meets your clinic's imaging requirements depends on your clinical workflow and approvals, so confirm this with your clinical IT team before ordering. For a clinic in Al Sadd or a hospital department in Doha, SmartRooms Qatar will confirm the required configuration before issuing the quotation.

Can it be used in a hot room or a lobby in Doha?

Its listed operating temperature is 0 to +40°C, with humidity of 20 to 80%. Summer temperatures in Qatar can go above 45°C, so the display should sit in an air-conditioned room that stays within that range. The front is rated IP40 and the back IP20, so avoid dusty areas and spots exposed to direct sunlight. Plan the air conditioning with your facilities team before installation.

Does it support 4K input?

No. The native resolution is 1920 x 1080 at 60 Hz, and the listed digital video resolutions top out at 1920 x 1080. The source data does not list 4K input, so do not plan 4K content on this model. If a school needs higher resolution, request a quote for a current replacement, and SmartRooms Qatar will review the output resolution of your existing source devices.

What is the OPS slot for?

The STv2 slot is compatible with the Intel and NEC OPS standard. The data lists optional modules for HD-SDI, an HDBaseT receiver and a slot-in PC, with Intel Core i5 or i7 recommended for the PC option. A conference centre might run presentation software from a slot-in PC, while a control room could use an HD-SDI module. The slot draws up to 61 W, so confirm the module you need before ordering.

How big is it and can it be wall-mounted?

Without the stand, the display measures 1294.4 x 765.2 x 86.5 mm and weighs 40.8 kg. It has a 300 x 300 mm VESA pattern with M6 holes. The manufacturer lists wall mount options including PDWHM-M and PDW S 32-55 L and P, plus a trolley option. Because of the weight, a free site survey is recommended to check wall structure, cable routes and viewing height before mounting.

Does it include speakers and a remote control?

Yes. The display has integrated 10 W + 10 W speakers and ships with a remote control. Optional 15 W + 15 W speakers are listed as an accessory, which may suit a large lecture hall better than the built-in pair. The shipping contents include a DVI-D cable, a power cable and a USB cable. Remote control and management are also possible over LAN and RS232.

How do schools or government bodies order several units?

SmartRooms Qatar supplies by quotation only. Buyers can order through a purchase order (LPO) or a government tender, including Monaqasat, and can pay by bank transfer, cheque or purchase order. A school fitting out several classrooms in Al Wakrah could standardise on one configuration, so one quotation can cover every unit, the wall mounts and the professional installation together. Quotations are usually issued within one working day.
