49VL5D

What the LG 49VL5D is built for

The LG 49VL5D is a 49-inch LCD panel designed to be tiled with other identical panels into one larger display. Each unit runs at 1,920 x 1,080 (FHD) and is rated at 450 nits typical module brightness. It is a narrow-bezel model, which matters when screens sit side by side and thick frames would break up content that spans the array.

Bezels, panel and colour consistency

The bezel measures 2.3 mm on the left and top and 1.2 mm on the right and bottom, so two adjacent panels leave a combined gap of 3.5 mm. The panel uses IPS technology, and the manufacturer links it to a high half-luminance viewing angle, which helps in walls mounted above eye level and viewed from several positions. Video Wall Image Creation circuitry compensates colour and brightness differences between panels, helping the array keep a consistent white balance.

A dedicated video wall menu lets operators set tile mode and white balance from the remote, and adjust colour temperature according to the content being shown.

Playback, control and networking

The panel has a quad-core SoC running webOS and internal memory for pre-loaded content, so it can display material without an external input. Where a separate player is preferred, the model accepts an external media player listed as MP500 or MP700. The management software named in the data is SuperSign Premium for content and SuperSign Link for control and monitoring. A LAN daisy chain lets operators control and monitor the wall, distribute content and update firmware across units from one connection.

Where it fits in Qatar

• Operations control rooms at energy or industrial sites in Mesaieed or Ras Laffan, where a wall of panels shows plant data and tight bezels keep it readable as one image.
• Corporate lobbies in West Bay or Lusail, where a video wall welcomes visitors and carries company messages in Arabic and English.
• Training and command rooms at universities or government offices, where a modest array presents live information to staff.

Planning for installation and environment

Each panel weighs 17.8 kg and measures 1077.6 mm x 607.8 mm x 89.7 mm. The VESA mount interface is 600 x 400 mm, a guide bracket is supplied, and optional landscape (WM-L640V) and portrait (WM-P640V) wall mounts are available. Because a wall carries many units, a free site survey before fixing brackets is sensible. The specified operating range is 0°C to 40°C with 10% to 80% humidity, so the wall should sit in an air-conditioned room. With Qatar summer temperatures above 45°C, avoid positions near unshaded windows or outdoor entrances. Typical power consumption is 93W, falling to 50W in smart energy saving mode. The power input is 100-240V, 50/60Hz, which includes Qatar's 240 V supply. Confirm plug and socket arrangements with the SmartRooms Qatar team before installation.

The LG 49VL5D has been discontinued by the manufacturer. If you already run this model and need matching units, or are comparing it with newer options, request a quote from SmartRooms Qatar. We will suggest a current equivalent or compatible replacement and issue a quotation, usually within one working day, with delivery to all 8 municipalities of Qatar and purchase orders accepted.
