LG 32SM5KE (Discontinued) · Replacements in Qatar

Name: LG 32SM5KE 32-inch FHD 400 nits Essential Signage Display
Brand: LG
SKU: lg-32sm5ke
Availability: Discontinued

Overview

The LG 32SM5KE is a discontinued 32-inch full HD signage display with webOS and built-in content management, so playlists can be edited without a separate PC. It offers 400 nits typical brightness, three HDMI inputs and a built-in speaker, suiting reception areas and corridors in Doha. Organisations that already run it, or are comparing alternatives, can request a quote for a current equivalent.

What the LG 32SM5KE does without a separate PC

The LG 32SM5KE is a 32-inch Full HD signage display from the SM5K series, and LG has discontinued it. This page is written for organisations that already run one, buyers comparing it with newer signage, and anyone who needs a like-for-like replacement for a unit that is in service.

A quad-core system-on-chip running webOS plays video, images and HTML content without an external media player. The embedded content management system lets staff create playlists and edit content on the display itself, so a site does not need a dedicated PC for every screen. Gapless playback removes black gaps between items, which keeps looping promotional content running smoothly.

Picture, inputs and control

The panel resolves 1,920 x 1,080 pixels and has a typical brightness of 400 cd/m2 (nits). Its inputs are three HDMI ports, DisplayPort, DVI-D, audio and USB 3.0, with a DisplayPort output and an audio output that can be set to off, fixed or variable. For remote management it provides RS232C in and out, an RJ45 port and an IR receiver. Live feeds can arrive over RTSP, RTP, HLS and UDP multicast streams.

Where it fits in Qatar

Reception and waiting areas: A 32-inch screen suits a clinic reception in Al Sadd or a corporate lobby in West Bay, showing wayfinding, schedules and announcements without overwhelming the space.
Split-screen retail: Picture-by-picture and picture-in-picture modes divide the screen into up to two sources in landscape or portrait, useful for a shop window in a Doha mall showing a product video beside a store directory.
Ticketing points: A USB thermal printer can be connected to issue tickets at a counter, for example in a bank branch in Msheireb or a desk near Hamad International Airport.

Outdoor and semi-outdoor use is not suitable. The stated operating temperature is 0°C to 40°C with humidity from 10% to 80%. Qatar summer temperatures can exceed 45°C, so the display should sit inside an air-conditioned building, away from glazed façades that receive direct sun. Confirm the exact location with the SmartRooms Qatar team before ordering.

Planning the mounting and power

The head measures 729.4 x 428.9 x 55.5 mm and weighs 5.4 kg, or 6.2 kg with the optional ST-322T stand. The VESA mount pattern is 200 x 200 mm, and the bezel is 13 mm on the sides and top and 18 mm at the bottom. The built-in power supply accepts 100-240 V at 50/60 Hz, and the unit is listed at 60 W typical and 85 W maximum. The model carries IEC/EN/UL 60950-1, FCC Class A, CE and KC approvals and Energy Star 8.0.

Optional accessories include the LSW230B wall bracket, the AM-B220S VESA adapter, the KT-OPSA OPS kit, the EB-B100 HDBaseT module and the KT-T32E touch overlay. Signage 365 Care is an optional cloud service for remote status checks and fault diagnosis. SmartRooms Qatar offers free site surveys, so wall construction, sockets and cable routes can be checked before installation.

Requesting a quote

Because this model is discontinued, the most useful step is a quote for a current equivalent or a compatible replacement that matches your screen size, mounting and content workflow. Send SmartRooms Qatar the number of screens, the locations and the connections you need, and the team will reply with a quotation, usually within one working day. Purchase orders (LPOs) and government tender documents are accepted, and payment can be made by bank transfer, cheque or purchase order.

Highlights

32-inch Full HD panel at 1,920 x 1,080 resolution
400 cd/m2 typical brightness
Quad-core webOS platform with embedded content management
Three HDMI inputs plus DisplayPort, DVI-D and USB 3.0
PBP and PIP split screens in landscape or portrait
Operating temperature 0°C to 40°C, humidity 10% to 80%
Built-in power supply rated 100-240 V, 50/60 Hz

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

29 specifications · Source: manufacturer · checked Oct 2026

PANEL3

Screen Size: 32"
Resolution: 1,920 x 1,080 (FHD)
Brightness(Typ.,cd/m²): 400

CONNECTIVITY3

Input: HDMI (3), DP, DVI-D, Audio, USB 3.0
Output: DP(SST), Audio(Off/Fixed/Variable)
External Control: RS232C In/out, RJ45 In, IR Receiver In

PHYSICAL SPECIFICATION8

Bezel Width: 13 mm (T/R/L), 18 mm (B)
Monitor Dimension (W x H x D): 729.4 x 428.9 x 55.5 mm
Weight (Head): 5.4 kg
Monitor with Optional Stand Dimensions (W x H x D): 729.4 x 481 x 154.2 mm
Weight (Head+Stand): 6.2 kg
Carton Dimensions (W x H x D): 810 x 510 x 132 mm
Packed Weight: 6.7 kg
VESA™ Standard Mount Interface: 200 x 200 mm

ENVIRONMENT CONDITIONS2

Operation Temperature: 0°C to 40°C
Operation Humidity: 10 % to 80 %

POWER2

Power Supply: 100-240 V~, 50/60 Hz
Power Type: Built-In Power

POWER CONSUMPTION2

Typ. / Max.: 60 W (TBD) / 85 W
Smart Energy Saving: 45 W (TBD)

STANDARD(CERTIFICATION)3

Safety: IEC 60950-1 / EN 60950-1 / UL 60950-1
EMC: FCC Class "A" / CE / KC
ErP / Energy Star: N/A / Yes (Energy Star 8.0)

MEDIA PLAYER COMPATIBILITY2

OPS Type Compatible: Yes
External Media Player Attatchable: Yes

SOFTWARE COMPATIBILITY2

Content Management Software: SuperSign CMS
Control and Monitoring Software: SuperSign Control+/Control

ACCESSORY2

Basic: Remote Controller (2ea batteries included), Power cord, QSG, HDMI cable, Regulation book, Phone to RS232C gender, Memory cover
Optional: Stand (ST-322T), Media Player, Wall Bracket (LSW230B), VESA Adapter (AM-B220S), OPS Kit (KT-OPSA), HDBaseT (EB-B100), Touch Overlay (KT-T32E)

Downloads

6 files from the manufacturer

PDF Manuals & guides · Opens on manufacturer site MFL70421401_05_IG_200324.pdf 4.8 MB PDF Manuals & guides · Opens on manufacturer site MFL70544411_01_32434955SH7E_SM5E_SM5KE_ENG.pdf 5.8 MB URL Manuals & guides · Opens on manufacturer site Owner's Manual (global) URL Manuals & guides · Opens on manufacturer site User Guide PDF Manuals & guides · Opens on manufacturer site webOS4.0_UG_ENG.pdf 4.4 MB URL Software & firmware · Opens on manufacturer site Software & Drivers (support page)

Questions about 32SM5KE

Is the LG 32SM5KE still sold by LG, and what should I buy instead?

LG has discontinued the 32SM5KE, so new units may be hard to source from the manufacturer. If you already run one, SmartRooms Qatar can quote a current equivalent or a compatible replacement that matches its 32-inch Full HD size and wall mounting. Send the number of screens, the locations and your current content workflow, and the team will confirm options within your quotation, usually within one working day.

What is the LG 32SM5KE best used for?

It is a 32-inch Full HD signage display for wayfinding, menus, announcements and promotional loops. Because the webOS platform and embedded content manager run without a separate PC, it suits a clinic reception in Al Sadd or a corporate lobby in West Bay where staff need to update messages themselves. Its 729.4 mm width suits corridors and feature walls where a larger panel would dominate the space.

Do I need an external media player with this model?

No. The quad-core system-on-chip plays video, images and HTML content without a separate media player. If you prefer a different playback device, the display is listed as compatible with an OPS type player and can take an external media player, and the optional KT-OPSA OPS kit is available. Confirm which option fits your existing content system before ordering.

How bright is the screen for a lobby with large windows?

The typical brightness is 400 cd/m2 (nits), which is best suited to indoor spaces with controlled lighting rather than sunlit façades. In a Doha lobby with large windows, position the screen away from direct light and check for reflections on glossy floors. A site survey from SmartRooms Qatar can check sightlines and lighting before the display is fixed in place.

Can it run in a non-air-conditioned area or outdoors in Qatar?

No. The stated operating temperature is 0°C to 40°C with humidity from 10% to 80%. Qatar summer temperatures can exceed 45°C, so the display should be installed inside an air-conditioned building, not in an open walkway, car park or outdoor kiosk. Confirm the exact spot with the SmartRooms Qatar team during the site survey before ordering.

Can I show two sources side by side on one screen?

Yes. Picture-by-picture (PBP) and picture-in-picture (PIP) modes divide the screen into up to two split areas, in landscape or portrait. A retailer in a Doha shopping mall could show a product video beside a store directory, or a hotel in West Bay could show the day's schedule beside a welcome message, with each source given its own area.

Which inputs and control options does it provide?

It has three HDMI inputs, one DisplayPort input, DVI-D, audio input and a USB 3.0 port, plus a DisplayPort (SST) output and an audio output. For control, it offers RS232C in and out, an RJ45 port and an IR receiver input. A USB thermal printer can also be connected to issue tickets at reception desks or bank counters.

Can it display a live video feed from a camera or encoder?

Yes. The display supports IP video streaming over RTSP, RTP, HLS and UDP multicast, so it can show live feeds without extra playback hardware. A university in Education City could relay a live event to lobby screens, or a logistics company could show a yard camera at its reception. Check your encoder's protocol against this list before purchase.

How much space and wall support do I need?

The head measures 729.4 x 428.9 x 55.5 mm and weighs 5.4 kg, or 6.2 kg with the optional ST-322T stand. The VESA mount is 200 x 200 mm, and the LSW230B wall bracket is an optional accessory. The bottom bezel is 18 mm. Free site surveys from SmartRooms Qatar can confirm wall construction and socket positions before installation.

Is the power supply suitable for Qatar, and which certifications apply?

The built-in power supply is rated 100-240 V at 50/60 Hz, a range that covers Qatar's 240 V mains supply. Typical consumption is listed at 60 W and maximum at 85 W. The model carries IEC/EN/UL 60950-1 safety approvals, FCC Class A, CE and KC EMC approvals and Energy Star 8.0. Ask the team to confirm that the supplied power cord suits your BS 1363 sockets.

Can a government entity or school buy this through a purchase order?

Yes. SmartRooms Qatar accepts purchase orders (LPOs) and government tenders, including through Monaqasat. A ministry or school ordering several units can raise one LPO against a single quotation, and payment can be made by bank transfer, cheque or purchase order. Include the quantity, the location of each screen and any optional stands or brackets so the quotation matches the order.
