Promethean AP9-B75 (Discontinued) · Replacements in Qatar

Name: Promethean ActivPanel 9 Premium AP9-B75 75-inch Interactive Display
Brand: Promethean
SKU: promethean-ap9-b75
Availability: Discontinued

Overview

The Promethean AP9-B75 is a 75-inch 4K interactive display from the ActivPanel 9 Premium series, and the manufacturer has discontinued it. It offers a 3840 x 2160 panel, 20-point touch, 8 GB of RAM, an OPS slot and 100 W USB-C power delivery. It suits mid-sized classrooms, training rooms and boardrooms across Qatar. Request a quote for this model or a current equivalent.

What the AP9-B75 is and where it stands

The AP9-B75 is the 75-inch model in Promethean's ActivPanel 9 Premium series, a large interactive display built for teaching, training and boardroom presentations. Promethean has discontinued this model and announced its end of sale. Organisations that already run one, and buyers comparing it with newer panels, should request a quote from SmartRooms Qatar for a current equivalent or a compatible replacement.

Picture quality and touch behaviour

The 4K UHD panel runs at 3840 x 2160 and 60 Hz across a 1652 x 930 mm active area in a 16:9 format. A direct LED backlight provides 400 cd/m² brightness and a 5000:1 dynamic contrast ratio, while the 178° viewing angle keeps text readable from the side seats of a room. Touch registers 20 points at once with 1 mm accuracy and a response time of 5 ms or less. Palm rejection works for both writing and non-writing hands, so a teacher can rest a hand on the glass while annotating.

Computing, connectivity and room integration

ActivPanel OS, an Android-based system, runs with 8 GB of RAM and 64 GB of internal storage. The rear of the panel offers two HDMI inputs (versions 2.0 and 2.1), a DisplayPort 1.2 input and a USB-C 3.2 Gen 1 port that supplies 100 W Power Delivery to a connected laptop. Other ports include a front HDMI 2.0 input, one OPS slot for an OPS computing module, 1 Gbps LAN in and out, and Wi-Fi supporting 802.11 a/b/g/n/ac/ax with Bluetooth 5.0. Two 18 W front speakers and a 15 W subwoofer work with a microphone array for lessons and meetings. The design has no fan.

Where it fits across Qatar

The 75-inch size suits mid-sized rooms rather than large halls. Three realistic scenarios:

A private school in Al Wakrah fitting out classrooms where Arabic and English lessons run side by side, using the front HDMI input for a visiting teacher's laptop.
A training centre in Education City equipping workshop rooms with the integrated pen tray and four pens so groups can annotate in turn.
A corporate boardroom in West Bay connecting presenters' laptops over HDMI or USB-C and sharing files directly from the panel.

What to plan before ordering

At 57.8 kg net and 78.5 kg packed, the panel needs at least two people to lift and a wall or stand rated for its weight. The VESA pattern is 800 x 400 mm and four M6 screws are in the box. Panel dimensions are 1730 x 1070 x 86 mm. A qualified installer should fit it, and SmartRooms Qatar recommends a free site survey before any wall mounting. The panel is rated for 0 °C to 40 °C with 20% to 80% non-condensing humidity. Qatar summer temperatures can exceed 45 °C, so it should sit in an air-conditioned room away from direct sun and dusty entrances. Confirm room conditions with our team before ordering. Typical power draw is 163 W, standby draw is 0.5 W or less, and the rated supply range covers 100 to 240 V AC.

Request a quote

Send your room dimensions, wall details and number of units to SmartRooms Qatar to request a quote for this model or a current equivalent. Quotations usually arrive within one working day. We supply and deliver to all 8 municipalities of Qatar, accept purchase orders (LPOs) and government tenders including Monaqasat, and take payment by bank transfer, cheque or purchase order. Products are covered by the manufacturer's warranty.

Highlights

75-inch 4K UHD panel at 3840 x 2160 resolution
20-point touch with 1 mm touch accuracy
8 GB RAM, 64 GB internal storage, ActivPanel OS
One OPS slot plus USB-C with 100 W Power Delivery
Operating range 0 °C to 40 °C; model is discontinued
Four pens, block eraser and ActivInspire Professional licence included

Classroom fit

At 75″ the farthest student should sit within about 5.6 m (6× the screen height).

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

96 specifications · Source: manufacturer · checked Oct 2026

Display18

Screen Size and Resolution: 65" 4K; UHD (3840 x 2160 @ 60 Hz) 75" 4K; UHD (3840 x 2160 @ 60 Hz) 86" 4K; UHD (3840 x 2160 @ 60 Hz)
Screen Type: TFT LCD (Direct LED Backlight)
Blue Light Reduction: Yes
Bonded Glass: Yes
Aspect Ratio: 16:9
Display Area: 65" 4K: 1429 x 804 mm (56.3 x 31.7 in) 75" 4K: 1652 x 930 mm (65 x 36.6 in) 86" 4K: 1895 x 1066 mm (74.6 x 41.9 in)
Display Colours: 1.07 Billion (10-bit)
LCD Viewing Angle: 178°
LCD Response Time: 8 ms
LCD Refresh Rate (Panel): 60 Hz
LCD Brightness (Brightness of display before cover glass): 455 cd/m²
LED Lifespan: 50,000 hours
Contrast Ratio: 5000:1 Dynamic 1200:1 Static
Brightness: 400 cd/m²
Ambient Light Sensor: Yes
Glass Hardness: 9H (pencil) , 7 (Mohs)
Glass Type: Heat tempered, Anti-Glare, Anti-Fingerprint
Glass Thickness: 4 mm

Interactivity19

Vellum Touch Technology: Yes
Continuous Touch Points: 20
Touch Resolution: 32768 x 32768 px
Response Time: ≤ 5 ms
Touch Accuracy: 1 mm
Tracking Rate: 4 m/s
Scan Rate: 200 Hz
Gestures and Edge Swipes: Windows ® supported
Eraser Included (Block Eraser): Yes
Unique Pen IDs: 2
Pen and Touch Differentiation: Yes
Palm Erase: Yes
Palm Rejection: Yes, writing and non-writing hand
Pens Included: Yes, 4
Pen Type: Battery-less pen
Pen Holder: Integrated full-length pen tray
Pen Tip Diameter: 3 mm (Eraser 7 mm)
Classroom Essential Apps: Including Explain Everything Whiteboard, Annotate, Timer, Spinner, Screen Capture, Screen Recording, Screen Share, Browser, PDF Reader, Media Player
Compatibility: Windows ® 7 to 11; Mac OS ® 10.8 to 10.11; macOS ® Sierra 10.12.1 or later; Linux ® Ubuntu 20.04 LTS; Chrome OS™

Computing8

Operating System: ActivPanel OS (Android-based)
RAM: 65": 6.5 GB 75": 8 GB 86": 8 GB
Internal Storage: 64 GB
CPU: ARM CORTEX - A73 x 4
GPU: ARM Mali-G52 2EE MC2
ActivSync™: Yes
Trusted Platform Module: Yes
Cloud Based User Profiles: Yes

Audio3

Dual Front-facing Speakers: 2 x 18 W
Subwoofer: 1 x 15 W
Microphone Array: Yes

Connectivity25

OPS Slot: 1
HDMI In (Rear): 2 (1 x 2.0, 1 x 2.1)
HDMI In (Front): 1 (2.0)
Display Port: 1 (1.2)
USB-A 2.0 (Rear): 1
USB-C 3.2 Gen 1 (Rear): 1 (100 W Power Delivery)
USB-B 3.2 Gen 1 (Touch, Front): 1
USB-B 3.2 Gen 1 (Touch, Rear): 3
USB-A 3.2 Gen 1 (Front): 2
USB-A 3.2 Gen 1 (Rear): 2
MicroSD Slot: Yes
LAN In (RJ45): 1 Gbps
LAN Out (RJ45): 1 Gbps
Wake-on-LAN: Yes
Wi-Fi (Client): IEEE 802.11 a/b/g/n/ac/ax, Wi-Fi 6 and dual band supported
Bluetooth: 5.0
HDMI Out: 1 (2.0)
VGA In: 1
PC Audio (3.5 mm): 1
AV-In (3.5 mm): 1
Mic (3.5 mm): 1
Audio Out (3.5 mm): 1
RS-232: 1
Proximity Sensor for Warm Boot: Yes
NFC (Near-field Communication): Yes Page 1

Panel Management2

OTA Updates: Yes
Promethean Admin Tools: Yes

Power3

Power Requirements: 100 V - 240 V AC
Energy Consumption (Typical): 65": 111 W 75": 163 W 86": 194 W
Ultra-Quiet Fanless Design: Yes

Environmental4

Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature: -15 °C to 55 °C (-5 °F to 131 °F)
Operating Humidity: 20% to 80% non-condensing humidity
Storage Humidity: 20% to 90% non-condensing humidity

Compliance & Certification2

Regulatory Certifications: CE, FCC, IC, UL, CUL, CB, RCM
Energy Star Certified: 65" 4K: Yes 75" 4K: Yes 86" 4K: Yes

Physical Specifications6

Panel Dimensions: 65": 1508 x 945 x 85 mm (59.4 x 37.2 x 3.3 in) 75": 1730 x 1070 x 86 mm (68.1 x 42.1 x 3.4 in) 86": 1974 x 1207 x 86 mm (77.7 x 47.5 x 3.4 in)
Packed Dimensions: 65": 1655 x 1035 x 225 mm (65.2 x 40.7 x 8.9 in) 75": 1870 x 1175 x 225 mm (73.6 x 46.2 x 8.9 in) 86": 2125 x 1295 x 260 mm (83.7 x 51 x 10.2 in)
Panel Net Weight: 65": 44.5 kg (98.1 lb) 75": 57.8 kg (127.4 lb) 86": 73.3 kg (161.6 lb)
Packed Weight: 65": 61.5 kg (135.6 lb) 75": 78.5 kg (173.1 lb) 86": 95.7 kg (211 lb)
Wall Mount Dimensions: 1010 x 720 x 52 mm (39.8 x 28.3 x 2.0 in)
VESA Mount Point: 65": 600 x 400 mm (23.6 x 15.7 in) 75": 800 x 400 mm (31.5 x 15.7 in) 86": 800 x 600 mm (31.5 x 23.6 in)

Education Software Licence1

ActivInspire ® Professional: Included

Packed Contents1

What’s in the Box: 1x ActivPanel 9 Premium 1x 3 m Length HDMI Cable 1x 3 m Length USB Cable (A-B) 1x 3 m Regional Power Cable 1x 2 m Length USB-C Cable 1x Remote Control 2x Batteries for Remote 4x Pens 1x Block Eraser 1x Sealed Antistatic Bag 8x Desiccant 4x VESA Mount Screws (M6) 1x Mini PC Bracket with Screws (x2) 2x NFC Cards 1x Quick Install Guide 1x Promethean Wi-Fi/Bluetooth Module 3x Antennae 1x Wi-Fi/Bluetooth Module User Guide 1x Wall Mount 2x Cable Management Hooks - 65" & 75" 3x Cable Management Hooks - 86"

Installation1

The installation of this product should be completed not supplied by Promethean or not meeting minimum safety and warranty. For more information, visit Support.PrometheanWorld.com.: by a qualified installer. Use of components specifications may impact performance,

Warranty1

Warranty term and upgrade options vary by region. information and visit PrometheanWorld.com/Warranty.: Contact your local reseller or distributor for

Support1

For all Promethean products, visit Support.PrometheanWorld.com.: Page 2

AP9-B751

size_inch: 75

Downloads

0 files from the manufacturer

No downloadable files are listed for this model yet. Ask us and we will send the datasheet.

Questions about AP9-B75

Is the Promethean AP9-B75 still sold?

No. Promethean has discontinued the AP9-B75 and announced its end of sale. SmartRooms Qatar can quote a current equivalent or a compatible replacement for your room, and quotations usually arrive within one working day. If you already run this 75-inch panel, send us your room plan and we will suggest the closest current option.

What screen size and resolution does the AP9-B75 have?

The AP9-B75 is a 75-inch display with a 4K UHD panel at 3840 x 2160 resolution and a 60 Hz refresh rate. Its active display area measures 1652 x 930 mm, and the panel itself measures 1730 x 1070 x 86 mm. The 16:9 format suits lesson slides, spreadsheets and video playback in a mid-sized room.

Is the 75-inch model right for a classroom in Qatar?

For a mid-sized classroom, usually yes. A private or Arabic-curriculum school in Al Wakrah or Al Rayyan fitting out a classroom gets a larger writing surface than the 65-inch model without the space demands of the 86-inch. The 178° viewing angle and 400 cd/m² brightness help students seated at the sides.

How does the 75-inch compare with the 65-inch and 86-inch versions?

The 75-inch sits between the two. Its display area is 1652 x 930 mm, against 1429 x 804 mm for the 65-inch and 1895 x 1066 mm for the 86-inch. It has 8 GB of RAM, where the 65-inch has 6.5 GB and the 86-inch matches it. Typical power draw is 163 W, compared with 111 W and 194 W.

Can it be installed in a sunny lobby or outdoor covered area in Qatar?

Not without checks. The operating range is 0 °C to 40 °C with 20% to 80% non-condensing humidity, and Qatar summer temperatures can exceed 45 °C. Keep it in an air-conditioned room away from direct sun, glazing and dust. Confirm the room conditions and cooling with the SmartRooms Qatar team before ordering.

What ports and expansion does it offer for laptops and media players?

The rear has two HDMI inputs (one 2.0, one 2.1), a DisplayPort 1.2 input and a USB-C 3.2 Gen 1 port with 100 W Power Delivery, which can power a connected laptop. The front adds an HDMI 2.0 input and two USB-A 3.2 ports. There is one OPS slot for an OPS computing module, plus 1 Gbps LAN in and out and an HDMI output.

Does it work with Windows, Mac and Chromebooks?

It supports Windows 7 to 11, Mac OS 10.8 to 10.11, macOS Sierra 10.12.1 or later, Linux Ubuntu 20.04 LTS and Chrome OS. Gestures and edge swipes are supported on Windows. Wi-Fi covers 802.11 a/b/g/n/ac/ax with Wi-Fi 6 and dual band, and Bluetooth 5.0 is included. Check your operating system version before ordering, especially for older Mac hardware.

What comes in the box?

The box includes the panel, a remote control with batteries, four pens, a block eraser, a wall mount, four M6 VESA screws, a 3 m regional power cable, a 3 m HDMI cable, a 3 m USB A-B cable, a 2 m USB-C cable, two NFC cards, and a Wi-Fi and Bluetooth module with three antennae. An ActivInspire Professional education software licence is included.

How heavy is it and what wall support does it need?

The panel weighs 57.8 kg net and 78.5 kg packed, so it needs at least two people to lift and a wall or stand rated for that load. The VESA mount pattern is 800 x 400 mm. A free site survey from SmartRooms Qatar lets us check the wall, cable route and access before a qualified installer fixes the panel.

Can a school or ministry order several units through an LPO or tender?

Yes. SmartRooms Qatar accepts purchase orders (LPOs) and government tenders, including Monaqasat, and accepts payment by bank transfer, cheque or purchase order. For a school fitting out several 75-inch rooms, send the room list with your request so the quotation covers each unit. Delivery covers all 8 municipalities of Qatar.

Will a 240 V supply in Qatar work with this panel?

The panel is rated for 100 to 240 V AC, so a 240 V supply falls within its rated range. A 3 m regional power cable is included. Typical power draw is 163 W, and standby draw is 0.5 W or less. Ask your electrician to confirm the outlet and circuit during the site survey, and we can include any extra cabling in the quotation.
