ViewSonic VB-STND-005 · Price in Qatar

Name: ViewSonic VB-STND-005 Slim Trolley Cart for 55 to 86-inch Displays
Brand: ViewSonic
SKU: viewsonic-vb-stnd-005
Availability: InStock

Overview

The ViewSonic VB-STND-005 is a height-adjustable mobile trolley for ViewBoard interactive panels from 55 to 86 inches, and the manufacturer lists it for displays up to 110 kg. Its 360-degree swivel, silent wheels with a stop brake and built-in pen tray make it practical for schools and meeting rooms that share one panel between several rooms. Request a quote for the right setup.

A movable stand for ViewBoard panels from 55 to 86 inches

The VB-STND-005 is a trolley cart made for ViewSonic ViewBoard interactive flat panels in the 55, 65, 75 and 86-inch sizes. The manufacturer also lists it for any display weighing up to 110 kg, so it can carry other panels within that limit. The frame is steel with plastic parts, and the height can be adjusted so the screen suits seated pupils in a primary classroom or standing presenters in a meeting room.

Mobility, swivel and braking

Quiet wheels let staff move the panel between rooms without disturbing a lesson or a meeting. The 360-degree swivel turns the cart to face the room from any angle, and the wheels include a stop brake that holds the cart still while you connect cables or present. A built-in tray holds pens and other small items within easy reach of the presenter.

Load limits, size and what to check before ordering

Panels from 55 to 86 inches, plus displays up to 110 kg as listed by the manufacturer
Plate rated at 10 kg maximum; keep heavier equipment off it
Wall mount loading rated at 100 kg maximum
Physical size 1170 x 1820 x 704 (W x H x D); packed size 1590 x 160 x 740
Net weight 26.9 kg; gross weight 31.8 kg

The source lists a wall mount bracket for displays from 55 to 98 inches, but it does not state whether that bracket ships with this model. Confirm the contents with SmartRooms Qatar before planning any wall installation. The box lists a Quick Start Guide and an accessory bag.

Where it fits in Qatar

A private school in Al Wakrah with one ViewBoard panel shared between two classrooms on different floors can wheel the screen to whichever room needs it for the next lesson. A training centre in Education City running workshops across several rooms can use one cart in place of a second fixed mount. In West Bay or Msheireb, a ministry or corporate office can roll a panel into a boardroom for a briefing and return it to a storage room afterwards.

Summer temperatures in Qatar regularly pass 45°C and dust storms are common. The source does not give an operating temperature range for this cart, so keep it in air-conditioned rooms and confirm the environment with the SmartRooms Qatar team before placing it near windows, glazed lobbies or unconditioned areas.

Planning the move

Before delivery, measure the doorways, lift and corridor widths on the route, and check the floor surface, since a cart of this weight with a large panel needs clear passage. A free site survey from SmartRooms Qatar covers these points and identifies where the cart will be parked when not in use. We supply to all eight municipalities of Qatar, offer professional installation, and accept LPOs and government tenders, including Monaqasat.

Request a quote from SmartRooms Qatar with your panel model and a room plan. Quotations are usually issued within one working day, and we will confirm the setup that suits your site.

Highlights

Fits ViewBoard panels from 55 to 86 inches
Listed for displays weighing up to 110 kg
360-degree swivel with silent wheels and stop brake
Height-adjustable design for moving between rooms
Integrated tray for pens and other small items
Net weight 26.9 kg with steel and plastic construction

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

11 specifications · Source: manufacturer · checked Oct 2026

Ergonomics2

Swivel: 360 degree
Height Adjust: Yes

Wall mount bracket1

Value: up to1070x600 ( 55"~98")

Material1

Value: Steel, Plastic

Loading2

Wall mount: 100 kg max. / 220.46 lb max.
Plate: 10 kg max. / 22.1 lb max

Dimensions2

Physical (WxHxD): 1170x1820x704
Packaging (WxHxD): 1590x160x740

Weight2

Net: 26.9kg / 59.3 lb
Gross: 31.8 kg/ 70.1 lb

Inbox items1

Value: Quick Start Guide, Accessory bag

Downloads

4 files from the manufacturer

PDF Datasheets VB-STND-005_Datasheet.pdf 202 KB PDF Manuals & guides 1289_20856_1595830502.pdf 856 KB PDF Manuals & guides VB-STND-005_QSG_ARB.pdf 1.5 MB PDF Other documents Silkscreen_VB-STND-005_20200226.pdf 1.7 MB

Questions about VB-STND-005

Which panels does the VB-STND-005 fit?

The VB-STND-005 is listed for ViewSonic ViewBoard panels in 55, 65, 75 and 86-inch sizes. The manufacturer also states it can hold any display weighing up to 110 kg. Before ordering, check your panel's model and weight against these limits, and ask SmartRooms Qatar to confirm the fit if you plan to use a display from another brand.

What is the maximum load on the cart?

The source data gives a 10 kg maximum for the plate and a 100 kg maximum for wall mount loading. The cart is also listed for displays up to 110 kg. Weigh your panel together with its accessories, keep heavier equipment off the plate, and avoid overloading the cart when you roll it over door thresholds between rooms.

Can one cart move a panel between classrooms in a Qatar school?

Yes, the source describes the cart for moving a panel from room to room. A private school in Al Wakrah with one ViewBoard panel shared by two classrooms on different floors can wheel the screen to the room that needs it. The 360-degree swivel helps aim the panel at the class, and the stop brake keeps it still while teachers connect cables before a lesson.

Are the wheels silent and do they lock in place?

The wheels are described as silent, which suits lessons, exams and meetings where noise carries. The wheels include a stop brake, so engage it before you leave the cart in position. On uneven floors or threshold strips between rooms, moving a heavy panel is safer with two people, and a site survey will identify where those obstacles are.

Can the height be adjusted for different users?

Yes, the VB-STND-005 is height adjustable. In a primary classroom in Doha the screen can be set for seated pupils, while in a boardroom in West Bay it can be raised for standing presenters. The source does not list a numerical height range, so ask SmartRooms Qatar for the minimum and maximum height before you finalise the room layout.

What are the dimensions and weight of the cart?

The cart's physical size is 1170 x 1820 x 704 (W x H x D), and its packed size is 1590 x 160 x 740. Net weight is 26.9 kg and gross weight is 31.8 kg. Measure lifts, doorways and corridors on your route, particularly in high-rise offices in Lusail or Doha, before delivery.

Is it suitable for hot areas or spaces near windows?

Summer temperatures in Qatar often exceed 45°C, and dust storms are common. The source does not give an operating temperature range for this cart, so no figure is stated here. Keep it in air-conditioned rooms, and ask SmartRooms Qatar to confirm the environment before placing it near windows, glazed lobbies or storage rooms without cooling.

Does the package include a wall mount bracket?

The source lists a wall mount bracket for displays from 55 to 98 inches, with a 100 kg maximum load. It does not confirm whether the bracket is supplied with this model. The listed box contents are a Quick Start Guide and an accessory bag, so ask for the full packing list before planning any wall installation.

Which panel size suits a lecture hall or a small room?

The cart accepts 55, 65, 75 and 86-inch ViewBoard panels, so the right size depends on the room. A 55 or 65-inch panel suits a small meeting room or a classroom in a private school in Al Sadd, while an 86-inch panel suits a lecture hall or boardroom in Education City or Lusail. Send your room dimensions with your quote request so we can check sightlines.

Do you supply schools and government offices on purchase orders?

Yes. SmartRooms Qatar supplies against purchase orders (LPOs) and government tenders, including Monaqasat, and accepts payment by bank transfer, cheque or purchase order. A school ordering several carts for several panels can cover all units on one LPO when they are requested together.

Is a site survey needed before delivery?

SmartRooms Qatar offers free site surveys. For this cart, a survey checks the route between rooms, including door widths, lift size, floor surfaces and thresholds, and identifies a parking spot for the cart when it is not in use. It is especially useful for a tall, heavy cart that will be moved across several floors.
