Name: Newline VNC Series 65, 75 and 86-inch Interactive Meeting Display
Brand: Newline
SKU: newline-vnc-series
Availability: Discontinued

Overview

The Newline VNC Series is a discontinued line of meeting room displays in 65, 75 and 86-inch sizes. Each has 4K resolution, optical bonding, infrared touch with up to 20 points, and a built-in 1080p camera and microphone array. Its 178° viewing angle suits meetings where people sit at the sides of the table. Organisations in Qatar that already run these panels, or need a similar meeting display, should request a quote for a current equivalent.

What the Newline VNC Series is built for

The Newline VNC Series is a meeting room display that combines a large 4K touch panel with a built-in camera, microphone array and speakers in a single unit. Newline has discontinued the line, so this page is written for organisations that already run these panels, buyers comparing them with newer meeting displays, and anyone who needs a like-for-like replacement. The series comes in three screen sizes: the TT-6519VNC at 65 inches, the TT-7519VNC at 75 inches and the TT-8619VNC at 86 inches.

Image quality and touch performance

Each model uses a 16:9 panel with 3840 x 2160 resolution, 370 nit brightness and a 4000:1 dynamic contrast ratio. Optical bonding fixes the glass to the LCD, which reduces reflection and parallax and keeps the picture clear from a wide angle rated at 178°. The anti-glare tempered glass has a 7H surface hardness. Infrared touch supports up to 20 points, using a stylus or a finger, so several people can write and annotate at the same time.

Sizes: 65, 75 and 86 inches
Resolution: 3840 x 2160 pixels
Touch: infrared, up to 20 points
Viewing angle: 178°
Platform: Android 8.0 with 4GB RAM and 32GB ROM

Camera, microphones and audio

The built-in CMOS camera records at 1920 x 1080 with a 90° viewing angle and sits below the front centre of the screen. A four-way microphone array picks up voices from up to 8 m away and applies echo cancellation, noise suppression and beam forming. Two 13 W speakers are built in. For larger spaces, an optional soundbar with 50 W output connects through the USB Type-C port.

Where it fits in Qatar

The 65-inch model suits a huddle room or a classroom at a school in Al Wakrah, where a small group works around one screen. The 75-inch model fits a department meeting room in a ministry building in Msheireb. The 86-inch model suits a boardroom in West Bay, where a leadership team joins calls with colleagues in other countries and needs shared documents visible across a long table. In each case the built-in camera and microphones mean the room needs fewer separate devices for a call.

Planning installation and the climate

The panels can be wall-mounted or fitted to a mobile stand, with VESA mounting positions of 600 x 400 mm and 800 x 400 mm. Weights run from approximately 34.7 kg for the 65-inch unit to 57.5 kg for the 86-inch unit, so book a free site survey before wall-mounting to check the wall, cable route and mounting height. Operating conditions are 0 to 40°C and 20 to 80% relative humidity, non-condensing, with storage from -10 to 45°C. Install the panels in air-conditioned rooms away from direct sun and window glare. The unit accepts 100 to 240 V AC at 50/60 Hz, a range that includes Qatar's 240 V, 50 Hz supply.

Because the VNC Series is discontinued, the quickest route is to tell the SmartRooms Qatar team which room, screen size and connections you need. Request a quote and we will recommend a current equivalent or compatible replacement, with the quotation usually issued within one working day. We supply on purchase orders and deliver to all eight municipalities of Qatar.

Highlights

65, 75 and 86-inch 4K panels with optical bonding
178° viewing angle with optically bonded glass
Infrared touch with up to 20 touch points
Built-in 1920 x 1080 camera and four-way microphone array
Wireless screen sharing over 2.4 GHz and 5 GHz Wi-Fi
Android 8.0 with 4GB RAM and 32GB ROM

Estimated timeline

Quotation within 1 working day · delivery timing depends on stock availability, and we confirm it with your quotation.

Specifications

11 specifications · Source: manufacturer · checked Oct 2026

VNC series11

Model Name: TT-6519VNC | TT-7519VNC | TT-8619VNC
Size: 65" | 75" | 86"
Display Area: 1428.48 x 803.52 mm | 1650.24 x 928.26 mm | 1895.04 x 1065.96mm
Weight: 34.7kg | 46kg | 57.5kg
Resolution: 3840 x 2160 pixels
Touch Technology: Infrared Touch
Touch Points: Up to 20 Points
Viewing Angle: 178°
Embedded Operating System: Android 8.0
RAM: 4GB
CPU: Hisilicon 811 ( A73 x 2 + A53 x 2 )

Downloads

4 files from the manufacturer

PDF Datasheets SpecSheet_Newline_VNC_202112.pdf 797 KB PDF Manuals & guides VNC-User-Manual-V2.2-Final.pdf 6.0 MB PDF Brochures Brochure_Corporate_FXAP_20191030.pdf 1.9 MB PDF Other documents VNC_FAQ.pdf 1.2 MB

Questions about VNC Series

Is the Newline VNC Series still in production?

No. Newline has discontinued the VNC Series, so this page covers the TT-6519VNC, TT-7519VNC and TT-8619VNC for buyers who already own them, are comparing them, or need a replacement. Request a quote and the SmartRooms Qatar team will recommend a current equivalent or a compatible replacement, with availability confirmed in the quotation.

Which size suits a small meeting room in Doha?

The 65-inch TT-6519VNC, with a display area of 1428.48 x 803.52 mm and a weight of 34.7 kg, is the best fit for a small room. The 75-inch TT-7519VNC at 46 kg suits a larger department room, and the 86-inch TT-8619VNC at 57.5 kg suits a boardroom. Check the wall and the viewing distance from the seats before choosing a size.

What resolution and brightness does the panel offer?

Each model has a 3840 x 2160 pixel resolution, a 16:9 display ratio, 370 nit brightness after the glass, a 4000:1 dynamic contrast ratio and an 8ms response time. The 178° viewing angle, supported by optical bonding, keeps the image clear for people seated at the sides of a meeting room. The panel uses an LED backlight with a blue light filter.

How good is the built-in camera and microphone?

The built-in CMOS camera records at 1920 x 1080 with a 90° viewing angle and sits below the front centre of the screen. The four-way microphone array picks up speech up to 8 m away and includes echo cancellation, noise suppression and beam forming. For a larger room, an optional soundbar with 50 W output can be connected through the USB Type-C port.

Can staff share laptops and phones wirelessly?

Yes. The display has built-in Wi-Fi on 2.4 GHz and 5 GHz, plus wireless screen sharing, so staff can present from their own device without cables. The manufacturer states compatibility with MAC, iOS, Windows and Android devices. HDMI inputs and a USB Type-C connection are also available for wired sharing when a meeting needs a cable.

How many people can write on the screen at the same time?

The infrared touch supports up to 20 touch points, so several people can write or annotate together. It accepts a stylus or a finger, and the anti-glare tempered glass has a 7H hardness rating. An on-screen annotation tool lets teams mark up shared content directly, which suits brainstorming sessions in boardrooms and training rooms.

We run video calls from a boardroom in West Bay. Is this panel suitable?

The 86-inch TT-8619VNC is the model to consider for a boardroom of that size. Its built-in camera and microphone array support remote participants, while the 4K panel shows shared documents clearly across a long table. If you need a wide-angle 4K camera, the optional soundbar includes one, so confirm the setup you need when requesting a quote.

Will a 65-inch unit suit a classroom at a school in Al Wakrah?

A 65-inch unit suits a classroom, training room or huddle room where a small group works around one screen. The 178° viewing angle helps students at the sides of the room see the content, and up to 20 touch points let several students write at once. At 34.7 kg, the panel should be mounted by a trained team after a site survey of the wall.

Can it sit in a reception area next to a window in summer?

Not without climate control. The operating range is 0 to 40°C at 20 to 80% relative humidity, non-condensing, and storage is rated from -10 to 45°C. Summer temperatures in Doha can exceed 45°C, so place the panel in an air-conditioned meeting room away from windows and direct sun, and confirm the position with the SmartRooms Qatar team during the site survey.

What power does it need in Qatar?

The working voltage is 100 to 240 V AC at 50/60 Hz, which includes Qatar's 240 V, 50 Hz supply. The maximum power draw is 300 W for the 65-inch model, 400 W for the 75-inch and 450 W for the 86-inch, with 0.5 W in standby. Plan a dedicated socket close to the mounting position, and confirm the socket type during the free site survey.

What mounting options and space are needed?

The panels can be wall-mounted or fitted to a mobile stand, with VESA mounting positions of 600 x 400 mm and 800 x 400 mm. Outline dimensions run from 1509 x 883 x 80 mm for the 65-inch unit to 1976 x 1147 x 81 mm for the 86-inch unit. Measure the wall and allow space for cable routing before ordering, and request a free site survey.

Can government offices and schools buy these through an LPO or a Monaqasat tender?

Yes. SmartRooms Qatar supplies on purchase orders (LPOs) and government tenders, including Monaqasat, and accepts payment by bank transfer, cheque or purchase order. If a school or ministry is fitting out several rooms, list each room with its screen size and mounting type in the request so the quotation covers every unit. Quotations are usually issued within one working day.
